Pre-loading paper mechanism, automatic fine-tuning function of paper table, non-stop cycle paper loading function (optional), saving paper changing time and improving work efficiency.
1. Pre-loading paper mechanism, automatic fine-tuning function of paper table, non-stop cycle paper loading function (optional), saving paper changing time and improving work efficiency.
2. The paper feeding bridge is driven by an independent servo motor, which can realize continuous overlapping paper feeding and single paper feeding.
3. The front stop gauge and the side pull regulation position, and the pull gauge/push gauge are alternately used to meet different thicknesses of paper. There is no indentation or flattening during paper feeding, which improves the quality of the product. One-key conversion, easy to use.
4. Use high-precision parts. The core components are manually ground, with high precision, good lubrication effect and high pressure, which can meet the die cutting of dense grid patterns.
Item | Parameters | |
Model | MY-1300 | MY-1500 |
Die cutting type | Pressed flat die cutting(Lower side is movable while upper side is unmovable) | Pressed flat die cutting(Lower side is movable while upper side is unmovable) |
Max paper transmitting size | 1320*980mm | 1510*1120mm |
Min paper transmitting size | 450*500mm | 450*500mm |
Max die cutting size | 1300*960mm | 1490*1100mm |
Min gripper size | 8mm | 8mm |
Max die cutting pressure | 350N/cm² | 380N/cm² |
Paper processed | Cardboard 200-2000 gsm | Cardboard 200-2000 gsm |
Max die cutting speed | 4500 sheets/h | 4500 sheets/h |
Main motor power | 11 kw | 11 kw |
Total power | ～18 kw | ～18 kw |
Total weight | ～7 T | ～18.5 T |
Overall size | 6670*2150*2346mm | 6870*2300*2346mm |
7700*4150*2346 | 7900*4300*2346 | |
Hebei Ouye Carton Machinery Manufacturer is a leading intelligent factory specializing in the design and manufacturing of carton packaging machinery. As a modern enterprise that integrates design, production, sales, and after-sales service, we pride ourselves on our innovative capabilities and extensive manufacturing experience. Our commitment to continuous improvement allows us to address the shortcomings of existing packaging machinery both domestically and internationally, propelling us towards the development of intelligent, high-speed, and energy-efficient automated machinery.
Q: Are you trading company or manufacturer?
A: We are manufacturer, and also provide the business solution to all the friends.
Q: How to control quality?
A: Our company has a team of engineers with excellent skills and many years of practical experience. The core components of the machine have dedicated suppliers and designated brands, with dual control from details to technology. Finally, each machine undergoes strict individual testing before shipment,we have CE,ISO9001 Quality Certificationetc.
Q: What's the delivery time?
A: Around 30~50days, however, based on order.
Q: What's payment terms, trade terms you accept?
A: Usually we appreciate T/T 30% deposit, then 70% balance is paid before shipment , we usually offer FOB tianjin price. but we also accept other way like L/C, wetern union, and do CFR&CIF etc.
Q: Does it easy to operate and what can i do if it doesn't work?
A: We suggest you to come to visit our factory to learn more thing by yourself, and if there is something goes wrong , you can call us, video-chat, email us. And we will give solutions within 36 hrs. Our engineer also can be distributed to overseas as you required.
